FIVER FIVER AUTOPARTS CO.,LTD — Chongqing

FIVER AUTOPARTS CO.,LTD

Toyota A/C compressor

Toyota AC Compressor Assy 88310-0K233, 883100K233 FORTUNER KUN156 2016-2018
Compressor assembly line, Chongqing
PRODUCTION PLATECompressor assembly line, Chongqing
Toyota A/C compressor

Toyota AC Compressor Assy 88310-0K233, 883100K233 FORTUNER KUN156 2016-2018

OE / Part number
88310-0K233, 883100K233

Remanufactured A/C Compressor for car OE No.:88310-0K233, 883100K233 Product Name:Toyota AC Compressor Assy Applications: FORTUNER KUN156 2016-2018

What arrives with every unit

  • TRACEProduction record filed against the order line.
  • TESTVacuum, pressure, noise and performance checked before packing.
  • SHIPExport packing with the packing list in the box.
  • SUPPORTApplication engineering available for fitment questions.

§ 01

Inside the compressor

A sectional drawing of a swash-plate compressor, with the six features that decide whether it holds pressure.

1 2 3 4 5 6
1

Control valve

Varies the swash-plate stroke to hold low-side suction pressure steady under changing load.

2

Drive pulley

Poly-V pulley driven from the engine belt; belt tension and alignment decide clutch life.

3

Rotor and swash plate

Pistons run on an inclined swash plate; the inclination sets displacement.

4

Piston and cylinder

Hardened, honed bores sized against the rotor so the swept volume stays on the drawing.

5

Suction port

Low-pressure refrigerant in. Pressure is verified against the test curve before the unit ships.

6

Discharge port

High-pressure gas out to the condenser. Leak tested on every unit.

§ 02

Data sheet

modelTOYOTA A/C Compressor / AUTO A/C compressor / FORTUNER A/C Compressor / compresor de aire
OE / Part number88310-0K233, 883100K233
ApplicationApplications: FORTUNER KUN156 2016-2018

§ 03

Product details

OE No.:88310-0K233, 883100K233
Product Name:Toyota AC Compressor Assy
Applications:FORTUNER KUN156 2016-2018

KUN156L-SNASYN
Year 2016 - 2018
Sales region General Frame KUN156 body SASUV ENGINE 1KDFTV TRANSMISSION ATM DESTINATION SA From 03.2016 Gear Shift Type 5FC Model Mark S Driver's Position LHD Fuel Induction DCR
KUN156L-SNFSYN
Year 2016 - 2018
Sales region General Frame KUN156 body SASUV ENGINE 1KDFTV TRANSMISSION MTM DESTINATION SA From 03.2016 Gear Shift Type 6F Model Mark S Driver's Position LHD Fuel Induction DCR
KUN156R-SNASYN
Year 2016 - 2018
Sales region General Frame KUN156 body SASUV ENGINE 1KDFTV TRANSMISSION ATM DESTINATION SA From 03.2016 Gear Shift Type 5FC Model Mark S Driver's Position RHD Fuel Induction DCR
KUN156R-SNFSYN
Year 2016 - 2018
Sales region General Frame KUN156 body SASUV ENGINE 1KDFTV TRANSMISSION MTM DESTINATION SA From 03.2016 Gear Shift Type 6F Model Mark S Driver's Position RHD Fuel Induction DCR
