AC Compressor Assy 88310-0R014, 883100R014 for Toyota Camry LE, SE, XLE, XSE 2.5L and RAV4RAV4. 2.5L
OE 88310-0R014, 883100R014
FIVER AUTOPARTS CO.,LTD
Toyota A/C compressor
Reemplazo del compresor de aire acondicionado del vehículo OE No.:88310-12B50, 8831012B50 Product Name:Compressor Assembly with W P Applications:COROLLA ALTIS NDE170 2014-2018
§ 01
A sectional drawing of a swash-plate compressor, with the six features that decide whether it holds pressure.
Control valve
Varies the swash-plate stroke to hold low-side suction pressure steady under changing load.
Drive pulley
Poly-V pulley driven from the engine belt; belt tension and alignment decide clutch life.
Rotor and swash plate
Pistons run on an inclined swash plate; the inclination sets displacement.
Piston and cylinder
Hardened, honed bores sized against the rotor so the swept volume stays on the drawing.
Suction port
Low-pressure refrigerant in. Pressure is verified against the test curve before the unit ships.
Discharge port
High-pressure gas out to the condenser. Leak tested on every unit.
§ 02
§ 03

OE No.:88310-12B50, 8831012B50
Product Name:Compressor Assembly with W P
Applications:COROLLA ALTIS NDE170 2014-2018
NDE170R-GEFEYX
Year 2014 - 2018
Sales region General Frame NDE170 grade G body SED ENGINE 1NDTV TRANSMISSION MTM DESTINATION IND From 05.2014 Gear Shift Type 6F No.of Doors 4D Driver's Position RHD Fuel Induction DCR
NDE170R-GEFGYX
Year 2014 - 2018
Sales region General Frame NDE170 grade GL body SED ENGINE 1NDTV TRANSMISSION MTM DESTINATION IND From 05.2014 Gear Shift Type 6F No.of Doors 4D Driver's Position RHD Fuel Induction DCR
§ 04
OE 88310-0R014, 883100R014
OE 88310-52720, 8831052720, 88310-0D400
OE 88310-52750, 8831052750
OE 88310-02850, 8831002850
