Products A/C compressor

Compressor Assembly with WP 88310-0K231, 883100K231;88310-0K232, 883100K232 FORTUNER

OE / Part number
88310-0K231, 883100K231, 88310-0K232, 883100K232

Compressor Assembly with WP 88310-0K231, 883100K231;88310-0K232, 883100K232 FORTUNER — aftermarket A/C compressor OE 88310-0K231 supplied by FIVER AUTOPARTS CO.,LTD. Send an inquiry for price and availability.

What arrives with every unit

  • TRACEProduction record filed against the order line.
  • TESTVacuum, pressure, noise and performance checked before packing.
  • SHIPExport packing with the packing list in the box.
  • SUPPORTApplication engineering available for fitment questions.

§ 01

Inside the compressor

A sectional drawing of a swash-plate compressor, with the six features that decide whether it holds pressure.

1 2 3 4 5 6
1

Control valve

Varies the swash-plate stroke to hold low-side suction pressure steady under changing load.

2

Drive pulley

Poly-V pulley driven from the engine belt; belt tension and alignment decide clutch life.

3

Rotor and swash plate

Pistons run on an inclined swash plate; the inclination sets displacement.

4

Piston and cylinder

Hardened, honed bores sized against the rotor so the swept volume stays on the drawing.

5

Suction port

Low-pressure refrigerant in. Pressure is verified against the test curve before the unit ships.

6

Discharge port

High-pressure gas out to the condenser. Leak tested on every unit.

§ 02

Data sheet

modelTOYOTA A/C compressor / AUTO A/C compressor / FORTUNER A/C Compressor
OE / Part number88310-0K231, 883100K231, 88310-0K232, 883100K232
ApplicationApplications: FORTUNER

§ 03

Product details

OE No.:88310-0K231, 883100K231;88310-0K232, 883100K232
Product Name:Compressor Assembly with W P
Applications:FORTUNER

KUN51 2011-2015
KUN60 2011-2015
KUN61 2011-2015

§ 04

Similar compressors

No.CompressorClutchPulley
