FIVER AUTOPARTS CO.,LTD
Toyota A/C compressor
Compressor Assembly for Avanza 1.5i with W P JK447220-4094
§ 01
A sectional drawing of a swash-plate compressor, with the six features that decide whether it holds pressure.
Control valve
Varies the swash-plate stroke to hold low-side suction pressure steady under changing load.
Drive pulley
Poly-V pulley driven from the engine belt; belt tension and alignment decide clutch life.
Rotor and swash plate
Pistons run on an inclined swash plate; the inclination sets displacement.
Piston and cylinder
Hardened, honed bores sized against the rotor so the swept volume stays on the drawing.
Suction port
Low-pressure refrigerant in. Pressure is verified against the test curve before the unit ships.
Discharge port
High-pressure gas out to the condenser. Leak tested on every unit.
§ 02
§ 03

Part Name: Compressor Assembly
OE: JK447220-4094
Applications: AVANZA 1.5i
Compressor Info:
Item No : WX-10042
Car Name : Avanza 1.5i
TYPE : 10S11E
Year model: 2003-
OEM No : JK447220-4094
Clutch information : 110mm 6PK 12V
Oil type : PAG 46
Oil Quantity : 120ml
§ 04
OE 88310-0R014, 883100R014
OE 88310-52720, 8831052720, 88310-0D400
OE 88310-52750, 8831052750
OE 88310-02850, 8831002850
