FIVER AUTOPARTS CO.,LTD

Toyota A/C compressor

Compresseur de climatisation pour véhicule88310-02A81, 8831002A81;88310-02A82, 8831002A82 LEVIN/ CERES/ TRUENO/ MARINOLEVIN/ CERES…
Compressor assembly line, Chongqing
PRODUCTION PLATECompressor assembly line, Chongqing
Toyota A/C compressor

Compresseur de climatisation pour véhicule88310-02A81, 8831002A81;88310-02A82, 8831002A82 LEVIN/ CERES/ TRUENO/ MARINOLEVIN/ CERES/ TRUENO/ MARINO ZRE181 2014-21016; ZRE182 2014-2017

OE / Part number
88310-02A81, 8831002A81, 88310-02A82, 8831002A82

Compresseur de climatisation pour véhicule88310-02A81, 8831002A81;88310-02A82, 8831002A82 LEVIN/ CERES/ TRUENO/ MARINOLEVIN/ CERES/ TRUENO/ MARINO ZRE181 2014-21016; ZRE182 2014-2017 — aftermarket A/C compressor OE 88310-02A81 supplied by FIVER AUTOPARTS CO.,LTD. Send an inquiry for price and availability.

What arrives with every unit

  • TRACEProduction record filed against the order line.
  • TESTVacuum, pressure, noise and performance checked before packing.
  • SHIPExport packing with the packing list in the box.
  • SUPPORTApplication engineering available for fitment questions.

§ 01

Inside the compressor

A sectional drawing of a swash-plate compressor, with the six features that decide whether it holds pressure.

1 2 3 4 5 6
1

Control valve

Varies the swash-plate stroke to hold low-side suction pressure steady under changing load.

2

Drive pulley

Poly-V pulley driven from the engine belt; belt tension and alignment decide clutch life.

3

Rotor and swash plate

Pistons run on an inclined swash plate; the inclination sets displacement.

4

Piston and cylinder

Hardened, honed bores sized against the rotor so the swept volume stays on the drawing.

5

Suction port

Low-pressure refrigerant in. Pressure is verified against the test curve before the unit ships.

6

Discharge port

High-pressure gas out to the condenser. Leak tested on every unit.

§ 02

Data sheet

modelTOYOTA A/C Compressor / LEVIN A/C Compressor / CERES A/C Compressor / TRUENO A/C Compressor
OE / Part number88310-02A81, 8831002A81, 88310-02A82, 8831002A82
ApplicationApplications: LEVIN/ CERES/ TRUENO/ MARINO

§ 03

Product details

OE No.:88310-02A81, 8831002A81;88310-02A82, 8831002A82
Product Name:Compresseur de climatisation pour véhicule
Applications:LEVIN/ CERES/ TRUENO/ MARINO

ZRE181 2014-21016
ZRE182 2014-2017


ZRE181L-CEMEKC
Year 2014 - 2016
Sales region General Frame ZRE181 body SED ENGINE 4ZRFE TRANSMISSION MTM Model LEVIN From 08.2014 To 11.2016 Gear Shift Type 5F No.of Doors 4D Vehicle Model Levin Model Mark E
ZRE181L-CEMNKC
Year 2014 - 2016
Sales region General Frame ZRE181 body SED ENGINE 4ZRFE TRANSMISSION MTM Model LEVIN From 08.2014 To 11.2016 Gear Shift Type 5F No.of Doors 4D Vehicle Model Levin Model Mark N
ZRE181L-CEXEKC
Year 2014 - 2016
Sales region General Frame ZRE181 body SED ENGINE 4ZRFE TRANSMISSION CVT Model LEVIN From 08.2014 To 11.2016 No.of Doors 4D Vehicle Model Levin Model Mark E
ZRE181L-CEXNKC
Year 2014 - 2016
Sales region General Frame ZRE181 body SED ENGINE 4ZRFE TRANSMISSION CVT Model LEVIN From 08.2014 To 11.2016 No.of Doors 4D Vehicle Model Levin Model Mark N ZRE182L-CEFGKC
Year 2014 - 2016
Sales region General Frame ZRE182 body SED ENGINE 7ZRFE TRANSMISSION MTM Model LEVIN From 08.2014 To 11.2016 Gear Shift Type 6F No.of Doors 4D Vehicle Model Levin Model Mark G
ZRE182L-CEXGKC
Year 2014 - 2017
Sales region General Frame ZRE182 body SED ENGINE 7ZRFE TRANSMISSION CVT Model LEVIN From 08.2014 To 06.2017 No.of Doors 4D Vehicle Model Levin Model Mark G
ZRE182L-CEXVKC
Year 2014 - 2017
Sales region General Frame ZRE182 body SED ENGINE 7ZRFE TRANSMISSION CVT Model LEVIN From 08.2014 To 06.2017 No.of Doors 4D Vehicle Model Levin Model Mark V
