FIVER FIVER AUTOPARTS CO.,LTD — Chongqing

FIVER AUTOPARTS CO.,LTD

Toyota A/C compressor

Compresor de aire acondionado 88310-12B00, 8831012B00 COROLLA AXIO/ FIELDER NRE160 2012-2018; NRE161 2015-2018
Compressor assembly line, Chongqing
PRODUCTION PLATECompressor assembly line, Chongqing
Toyota A/C compressor

Compresor de aire acondionado 88310-12B00, 8831012B00 COROLLA AXIO/ FIELDER NRE160 2012-2018; NRE161 2015-2018

OE / Part number
88310-12B00, 8831012B00

Reemplazo del compresor de aire acondicionado del vehículo OE No.:88310-12B00, 8831012B00 Product Name:Compresor de aire acondionado Applications:COROLLA AXIO/ FIELDER NRE160 2012-2018 NRE161 2015-2018

What arrives with every unit

  • TRACEProduction record filed against the order line.
  • TESTVacuum, pressure, noise and performance checked before packing.
  • SHIPExport packing with the packing list in the box.
  • SUPPORTApplication engineering available for fitment questions.

§ 01

Inside the compressor

A sectional drawing of a swash-plate compressor, with the six features that decide whether it holds pressure.

1 2 3 4 5 6
1

Control valve

Varies the swash-plate stroke to hold low-side suction pressure steady under changing load.

2

Drive pulley

Poly-V pulley driven from the engine belt; belt tension and alignment decide clutch life.

3

Rotor and swash plate

Pistons run on an inclined swash plate; the inclination sets displacement.

4

Piston and cylinder

Hardened, honed bores sized against the rotor so the swept volume stays on the drawing.

5

Suction port

Low-pressure refrigerant in. Pressure is verified against the test curve before the unit ships.

6

Discharge port

High-pressure gas out to the condenser. Leak tested on every unit.

§ 02

Data sheet

modeltOYOTA A/C Compressor / AUTO A/C compressor / COROLLA A/C compressor / FiLEDER A/C Compressor
OE / Part number88310-12B00, 8831012B00
ApplicationApplications: COROLLA AXIO/ FIELDER

§ 03

Product details

OE No.:88310-12B00, 8831012B00
Product Name:Compresor de aire acondionado
Applications:COROLLA AXIO/ FIELDER

NRE160 2012-2018
NRE161 2015-2018

NRE160-AEXNK
Year 2012 - 2018
Sales region Japan Frame NRE160 grade X body SED ENGINE 1NRFE TRANSMISSION CVT Model COROLLA AXIO From 04.2012 No.of Doors 4D Vehicle Model Corolla AxioNRE161-AEXEB
Year 2015 - 2018
Sales region Japan Frame NRE161 grade G body SED ENGINE 2NRFKE TRANSMISSION CVT Model COROLLA AXIO From 03.2015 No.of Doors 4D Vehicle Model Corolla Axio
NRE161-AEXNB
Year 2015 - 2018
Sales region Japan Frame NRE161 grade X body SED ENGINE 2NRFKE TRANSMISSION CVT Model COROLLA AXIO From 03.2015 No.of Doors 4D Vehicle Model Corolla Axio
NRE161G-AWXEB
Year 2015 - 2018
Sales region Japan Frame NRE161 grade G body WG ENGINE 2NRFKE TRANSMISSION CVT Model COROLLA FIELDER From 03.2015 No.of Doors 5D Vehicle Model Corolla Fielder
NRE161G-AWXNB
Year 2015 - 2018
Sales region Japan Frame NRE161 grade X body WG ENGINE 2NRFKE TRANSMISSION CVT Model COROLLA FIELDER From 03.2015 No.of Doors 5D Vehicle Model Corolla Fielder
NRE161R-AEXEB
Year 2015 - 2018
Sales region General Frame NRE161 body SED ENGINE 2NRFKE TRANSMISSION CVT Model COROLLA AXIO From 03.2015 No.of Doors 4D Vehicle Model Corolla Axio Model Mark E Driver's Position RHD
NRE161R-AEXNB
Year 2015 - 2018
Sales region General Frame NRE161 body SED ENGINE 2NRFKE TRANSMISSION CVT Model COROLLA AXIO From 03.2015 No.of Doors 4D Vehicle Model Corolla Axio Model Mark N Driver's Position RHD
NRE161R-AWXNB
Year 2015 - 2018
Sales region General Frame NRE161 body WG ENGINE 2NRFKE TRANSMISSION CVT Model COROLLA FIELDER From 03.2015 No.of Doors 5D Vehicle Model Corolla Fielder Model Mark N Driver's Position RHD

§ 04

Similar compressors
