FIVER FIVER AUTOPARTS CO.,LTD — Chongqing

FIVER AUTOPARTS CO.,LTD

Toyota A/C compressor

Compresor de aire acondionado 88310-0DA60, 883100DA60 YARIS/ ECHO/ VIOS/ LIMO NSP130 2014-2017; NSP131 2017-2018
Compressor assembly line, Chongqing
PRODUCTION PLATECompressor assembly line, Chongqing
Toyota A/C compressor

Compresor de aire acondionado 88310-0DA60, 883100DA60 YARIS/ ECHO/ VIOS/ LIMO NSP130 2014-2017; NSP131 2017-2018

OE / Part number
88310-0DA60, 883100DA60

Compresor de aire acondicionado automático de calidad estándar OE OE No.:88310-0DA60, 883100DA60 Product Name:Compresor de aire acondionado Applications:YARIS/ ECHO/ VIOS/ LIMO NSP130 2014-2017 NSP131 2017-2018

What arrives with every unit

  • TRACEProduction record filed against the order line.
  • TESTVacuum, pressure, noise and performance checked before packing.
  • SHIPExport packing with the packing list in the box.
  • SUPPORTApplication engineering available for fitment questions.

§ 01

Inside the compressor

A sectional drawing of a swash-plate compressor, with the six features that decide whether it holds pressure.

1 2 3 4 5 6
1

Control valve

Varies the swash-plate stroke to hold low-side suction pressure steady under changing load.

2

Drive pulley

Poly-V pulley driven from the engine belt; belt tension and alignment decide clutch life.

3

Rotor and swash plate

Pistons run on an inclined swash plate; the inclination sets displacement.

4

Piston and cylinder

Hardened, honed bores sized against the rotor so the swept volume stays on the drawing.

5

Suction port

Low-pressure refrigerant in. Pressure is verified against the test curve before the unit ships.

6

Discharge port

High-pressure gas out to the condenser. Leak tested on every unit.

§ 02

Data sheet

modelTOYOTA A/C Compressor / YARIS A/C Compressor / ECHO A/C Compressor / VIOS A/C compressors
OE / Part number88310-0DA60, 883100DA60
ApplicationApplications: YARIS/ ECHO/ VIOS/ LIMO

§ 03

Product details

OE No.:88310-0DA60, 883100DA60
Product Name:Compresor de aire acondionado
Applications:YARIS/ ECHO/ VIOS/ LIMO

NSP130 2014-2017
NSP131 2017-2018


NSP130L-CGFNKW
Year 2014 - 2017
Sales region Europe Frame NSP130 ENGINE 1NRFE TRANSMISSION MTM PRODUCT FRP From 07.2014 To 03.2017 Gear Shift Type 6F No.of Doors 3D Model Mark N Driver's Position LHD
NSP130L-CGFRKW
Year 2014 - 2017
Sales region Europe Frame NSP130 ENGINE 1NRFE TRANSMISSION MTM PRODUCT FRP From 07.2014 To 03.2017 Gear Shift Type 6F No.of Doors 3D Model Mark R Driver's Position LHD
NSP130L-CGXNKW
Year 2014 - 2017
Sales region Europe Frame NSP130 ENGINE 1NRFE TRANSMISSION CVT PRODUCT FRP From 07.2014 To 03.2017 No.of Doors 3D Model Mark N Driver's Position LHD
NSP130L-CHFGKW
Year 2014 - 2017
Sales region Europe Frame NSP130 ENGINE 1NRFE TRANSMISSION MTM PRODUCT FRP From 07.2014 To 03.2017 Gear Shift Type 6F No.of Doors 5D Model Mark G Driver's Position LHD
NSP130L-CHFNKW
Year 2014 - 2017
Sales region Europe Frame NSP130 ENGINE 1NRFE TRANSMISSION MTM PRODUCT FRP From 07.2014 To 03.2017 Gear Shift Type 6F No.of Doors 5D Model Mark N Driver's Position LHD
NSP130L-CHFRKW
Year 2014 - 2017
Sales region Europe Frame NSP130 ENGINE 1NRFE TRANSMISSION MTM PRODUCT FRP From 07.2014 To 03.2017 Gear Shift Type 6F No.of Doors 5D Model Mark R Driver's Position LHD
NSP130L-CHFSKW
Year 2014 - 2017
Sales region Europe Frame NSP130 ENGINE 1NRFE TRANSMISSION MTM PRODUCT FRP From 07.2014 To 03.2017 Gear Shift Type 6F No.of Doors 5D Model Mark S Driver's Position LHD
NSP130L-CHXGKW
Year 2014 - 2017
Sales region Europe Frame NSP130 ENGINE 1NRFE TRANSMISSION CVT PRODUCT FRP From 07.2014 To 03.2017 No.of Doors 5D Model Mark G Driver's Position LHD
NSP130L-CHXNKW
Year 2014 - 2017
Sales region Europe Frame NSP130 ENGINE 1NRFE TRANSMISSION CVT PRODUCT FRP From 07.2014 To 03.2017 No.of Doors 5D Model Mark N Driver's Position LHD
NSP130L-CHXSKW
Year 2014 - 2017
Sales region Europe Frame NSP130 ENGINE 1NRFE TRANSMISSION CVT PRODUCT FRP From 07.2014 To 03.2017 No.of Doors 5D Model Mark S Driver's Position LHDNSP131L-CGFNBW
Year 2017 - 2018
Sales region Europe Frame NSP131 ENGINE 2NRFKE TRANSMISSION MTM PRODUCT FRP From 03.2017 Gear Shift Type 6F No.of Doors 3D Model Mark N Driver's Position LHD
NSP131L-CGFRBW
Year 2017 - 2018
Sales region Europe Frame NSP131 ENGINE 2NRFKE TRANSMISSION MTM PRODUCT FRP From 03.2017 Gear Shift Type 6F No.of Doors 3D Model Mark R Driver's Position LHD
NSP131L-CGXNBW
Year 2017 - 2018
Sales region Europe Frame NSP131 ENGINE 2NRFKE TRANSMISSION CVT PRODUCT FRP From 03.2017 No.of Doors 3D Model Mark N Driver's Position LHD
NSP131L-CHFGBW
Year 2017 - 2018
Sales region Europe Frame NSP131 ENGINE 2NRFKE TRANSMISSION MTM PRODUCT FRP From 03.2017 Gear Shift Type 6F No.of Doors 5D Model Mark G Driver's Position LHD
NSP131L-CHFNBW
Year 2017 - 2018
Sales region Europe Frame NSP131 ENGINE 2NRFKE TRANSMISSION MTM PRODUCT FRP From 03.2017 Gear Shift Type 6F No.of Doors 5D Model Mark N Driver's Position LHD
NSP131L-CHFRBW
Year 2017 - 2018
Sales region Europe Frame NSP131 ENGINE 2NRFKE TRANSMISSION MTM PRODUCT FRP From 03.2017 Gear Shift Type 6F No.of Doors 5D Model Mark R Driver's Position LHD
NSP131L-CHFSBW
Year 2017 - 2018
Sales region Europe Frame NSP131 ENGINE 2NRFKE TRANSMISSION MTM PRODUCT FRP From 03.2017 Gear Shift Type 6F No.of Doors 5D Model Mark S Driver's Position LHD
NSP131L-CHXGBW
Year 2017 - 2018
Sales region Europe Frame NSP131 ENGINE 2NRFKE TRANSMISSION CVT PRODUCT FRP From 03.2017 No.of Doors 5D Model Mark G Driver's Position LHD
NSP131L-CHXNBW
Year 2017 - 2018
Sales region Europe Frame NSP131 ENGINE 2NRFKE TRANSMISSION CVT PRODUCT FRP From 03.2017 No.of Doors 5D Model Mark N Driver's Position LHD
NSP131L-CHXSBW
Year 2017 - 2018
Sales region Europe Frame NSP131 ENGINE 2NRFKE TRANSMISSION CVT PRODUCT FRP From 03.2017 No.of Doors 5D Model Mark S Driver's Position LHD
