Toyota A/C compressor

Compresor de aire acondionado 88310-02A12, 8831002A12 COROLLA ALTIS ZRE172 2014-2018
Compressor assembly line, Chongqing
PRODUCTION PLATECompressor assembly line, Chongqing
Toyota A/C compressor

Compresor de aire acondionado 88310-02A12, 8831002A12 COROLLA ALTIS ZRE172 2014-2018

OE / Part number
88310-02A12, 8831002A12

Remanufactured A/C Compressor for car OE No.:88310-02A12, 8831002A12 Product Name:Compresor de aire acondionado Applications:COROLLA ALTIS ZRE172 2014-2018

What arrives with every unit

  • TRACEProduction record filed against the order line.
  • TESTVacuum, pressure, noise and performance checked before packing.
  • SHIPExport packing with the packing list in the box.
  • SUPPORTApplication engineering available for fitment questions.

§ 01

Inside the compressor

A sectional drawing of a swash-plate compressor, with the six features that decide whether it holds pressure.

1 2 3 4 5 6
1

Control valve

Varies the swash-plate stroke to hold low-side suction pressure steady under changing load.

2

Drive pulley

Poly-V pulley driven from the engine belt; belt tension and alignment decide clutch life.

3

Rotor and swash plate

Pistons run on an inclined swash plate; the inclination sets displacement.

4

Piston and cylinder

Hardened, honed bores sized against the rotor so the swept volume stays on the drawing.

5

Suction port

Low-pressure refrigerant in. Pressure is verified against the test curve before the unit ships.

6

Discharge port

High-pressure gas out to the condenser. Leak tested on every unit.

§ 02

Data sheet

modelTOYOTA A/C Compressor / AUTO A/C compressor / COROLLA A/C compressor / ALTIS A/C Compressor
OE / Part number88310-02A12, 8831002A12
ApplicationApplications: COROLLA ALTIS ZRE172 2014-2018

§ 03

Product details

OE No.:88310-02A12, 8831002A12
Product Name:Compresor de aire acondionado
Applications:COROLLA ALTIS ZRE172 2014-2018


ZRE172R-GEFDKX
Year 2014 - 2018
Sales region General Frame ZRE172 grade J body SED ENGINE 2ZRFE TRANSMISSION MTM DESTINATION IND From 05.2014 Gear Shift Type 6F No.of Doors 4D Driver's Position RHD Fuel Induction HTWC
ZRE172R-GEFEKX
Year 2014 - 2018
Sales region General Frame ZRE172 grade G body SED ENGINE 2ZRFE TRANSMISSION MTM DESTINATION IND From 05.2014 Gear Shift Type 6F No.of Doors 4D Driver's Position RHD Fuel Induction HTWC
ZRE172R-GEFGKX
Year 2014 - 2018
Sales region General Frame ZRE172 grade GL body SED ENGINE 2ZRFE TRANSMISSION MTM DESTINATION IND From 05.2014 Gear Shift Type 6F No.of Doors 4D Driver's Position RHD Fuel Induction HTWC
ZRE172R-GEXEKX
Year 2014 - 2018
Sales region General Frame ZRE172 grade G body SED ENGINE 2ZRFE TRANSMISSION CVT DESTINATION IND From 05.2014 No.of Doors 4D Driver's Position RHD Fuel Induction HTWC
ZRE172R-GEXGKX
Year 2014 - 2018
Sales region General Frame ZRE172 grade VL body SED ENGINE 2ZRFE TRANSMISSION CVT DESTINATION IND From 05.2014 No.of Doors 4D Driver's Position RHD Fuel Induction HTWC
