Toyota A/C compressor
A/C Compressor 88320-0C010,883200C010 for Land Cruiser 4.7 V8 32V/Tundra 4.7 V8 32V /Super Grandia
§ 01
A sectional drawing of a swash-plate compressor, with the six features that decide whether it holds pressure.
Control valve
Varies the swash-plate stroke to hold low-side suction pressure steady under changing load.
Drive pulley
Poly-V pulley driven from the engine belt; belt tension and alignment decide clutch life.
Rotor and swash plate
Pistons run on an inclined swash plate; the inclination sets displacement.
Piston and cylinder
Hardened, honed bores sized against the rotor so the swept volume stays on the drawing.
Suction port
Low-pressure refrigerant in. Pressure is verified against the test curve before the unit ships.
Discharge port
High-pressure gas out to the condenser. Leak tested on every unit.
§ 02
§ 03

Part Name: A/C Compressor
OE Code: 88320-0C010,883200C010
Applications: Land Cruiser 4.7 V8 32V/Tundra 4.7 V8 32V /Super Grandia
Compressor Info:
Item No : WX-10025
Car Name : Land Cruiser 4.7 V8 32V/Tundra 4.7 V8 32V /Super Grandia
TYPE : 10S17C
Year model: 2001-2006
OEM No : 88320-0C010
Clutch information : 120mm 6PK 12V
Oil type : PAG 46
Oil quantity: 200ml
§ 04
OE 88310-0R014, 883100R014
OE 88310-52720, 8831052720, 88310-0D400
OE 88310-52750, 8831052750
OE 88310-02850, 8831002850
