Honda A/C compressor

Buy A/C Compressor Online 38800-PH4-663, 38800PH4663, 38800-PH4-663RM for Accord 1989
Compressor assembly line, Chongqing
PRODUCTION PLATECompressor assembly line, Chongqing
Honda A/C compressor

Buy A/C Compressor Online 38800-PH4-663, 38800PH4663, 38800-PH4-663RM for Accord 1989

OE / Part number
38800-PH4-663, 38800PH4663, 38800-PH4-663RM

Buy A/C Compressor Online 38800-PH4-663, 38800PH4663, 38800-PH4-663RM for Accord 1989

What arrives with every unit

  • TRACEProduction record filed against the order line.
  • TESTVacuum, pressure, noise and performance checked before packing.
  • SHIPExport packing with the packing list in the box.
  • SUPPORTApplication engineering available for fitment questions.

§ 01

Inside the compressor

A sectional drawing of a swash-plate compressor, with the six features that decide whether it holds pressure.

1 2 3 4 5 6
1

Control valve

Varies the swash-plate stroke to hold low-side suction pressure steady under changing load.

2

Drive pulley

Poly-V pulley driven from the engine belt; belt tension and alignment decide clutch life.

3

Rotor and swash plate

Pistons run on an inclined swash plate; the inclination sets displacement.

4

Piston and cylinder

Hardened, honed bores sized against the rotor so the swept volume stays on the drawing.

5

Suction port

Low-pressure refrigerant in. Pressure is verified against the test curve before the unit ships.

6

Discharge port

High-pressure gas out to the condenser. Leak tested on every unit.

§ 02

Data sheet

modelBuy A/C Compressor Online / HONDA Auto A/C Compressor / A/C Compressor manufacturer China / Honda Accord A/C Compressor
OE / Part number38800-PH4-663, 38800PH4663, 38800-PH4-663RM
ApplicationAPPLICATIONS: Accord 1989 2 Door DX, 3 Door DX, 4 Door DX KA 4AT, KA 5MT, KL 4AT, KL 5MT Accord 1988 2 Door DX KA 4AT, KA 5MT, KL 4AT, KL 5MT Accord 1987 3 Door DX, 4 Door DX, 4 Door LX KA 4AT, KA 5MT, KL 4AT, KL 5MT

§ 03

Product details

PART NAME:Buy A/C Compressor Online
OE CODE/ CROSS REFERENCE:38800-PH4-663, 38800PH4663, 38800-PH4-663RM

APPLICATIONS:Accord 1989 2 Door DX, 3 Door DX, 4 Door DX KA 4AT, KA 5MT, KL 4AT, KL 5MT Accord 1988 2 Door DX KA 4AT, KA 5MT, KL 4AT, KL 5MT Accord 1987 3 Door DX, 4 Door DX, 4 Door LX KA 4AT, KA 5MT, KL 4AT, KL 5MT

§ 04

Similar compressors

No.CompressorClutchPulley
