Toyota A/C compressor

Auto AC Compressor Assy88310-BZ530, 88310BZ530 AVANZA F652 2014-2015
Compressor assembly line, Chongqing
PRODUCTION PLATECompressor assembly line, Chongqing
Toyota A/C compressor

Auto AC Compressor Assy88310-BZ530, 88310BZ530 AVANZA F652 2014-2015

OE / Part number
88310-BZ530, 88310BZ530

OE standard Quality Auto A/C Compressor OE No.:88310-BZ530, 88310BZ530 Product Name:Auto AC Compressor Assy Applications:AVANZA F652 2014-2015

What arrives with every unit

  • TRACEProduction record filed against the order line.
  • TESTVacuum, pressure, noise and performance checked before packing.
  • SHIPExport packing with the packing list in the box.
  • SUPPORTApplication engineering available for fitment questions.

§ 01

Inside the compressor

A sectional drawing of a swash-plate compressor, with the six features that decide whether it holds pressure.

1 2 3 4 5 6
1

Control valve

Varies the swash-plate stroke to hold low-side suction pressure steady under changing load.

2

Drive pulley

Poly-V pulley driven from the engine belt; belt tension and alignment decide clutch life.

3

Rotor and swash plate

Pistons run on an inclined swash plate; the inclination sets displacement.

4

Piston and cylinder

Hardened, honed bores sized against the rotor so the swept volume stays on the drawing.

5

Suction port

Low-pressure refrigerant in. Pressure is verified against the test curve before the unit ships.

6

Discharge port

High-pressure gas out to the condenser. Leak tested on every unit.

§ 02

Data sheet

modelTOYOTA A/C Compressor / AUTO A/C compressor / AVANZA A/C Compressor
OE / Part number88310-BZ530, 88310BZ530
ApplicationApplications: AVANZA F652 2014-2015

§ 03

Product details

OE No.:88310-BZ530, 88310BZ530
Product Name:Auto AC Compressor Assy
Applications:AVANZA F652 2014-2015


F652LM-GMDFV
Year 2014 - 2015
Sales region U.S.A. Frame F652 grade STD body VAN ENGINE 3SZVE DESTINATION GCC From 04.2014 To 08.2015 Gear Shift Type 5F Driver's Position LHD Fuel Induction WVVT
F652LM-GMMFV
Year 2014 - 2015
Sales region U.S.A. Frame F652 grade MID body VAN ENGINE 3SZVE DESTINATION GCC From 04.2014 To 08.2015 Gear Shift Type 5F Driver's Position LHD Fuel Induction WVVT
F652LM-GQDFV
Year 2014 - 2015
Sales region U.S.A. Frame F652 grade STD body VAN ENGINE 3SZVE DESTINATION GCC From 04.2014 To 08.2015 Gear Shift Type 4AT Driver's Position LHD Fuel Induction WVVT
F652LM-GQMFV
Year 2014 - 2015
Sales region U.S.A. Frame F652 grade MID body VAN ENGINE 3SZVE DESTINATION GCC From 04.2014 To 08.2015 Gear Shift Type 4AT Driver's Position LHD Fuel Induction WVVT
F652LM-GMDFV
Year 2014 - 2015
Sales region General Frame F652 grade STD body VAN ENGINE 3SZVE DESTINATION GCC From 04.2014 To 08.2015 Gear Shift Type 5F Driver's Position LHD Fuel Induction WVVT
F652LM-GMMFV
Year 2014 - 2015
Sales region General Frame F652 grade MID body VAN ENGINE 3SZVE DESTINATION GCC From 04.2014 To 08.2015 Gear Shift Type 5F Driver's Position LHD Fuel Induction WVVT
F652LM-GQDFV
Year 2014 - 2015
Sales region General Frame F652 grade STD body VAN ENGINE 3SZVE DESTINATION GCC From 04.2014 To 08.2015 Gear Shift Type 4AT Driver's Position LHD Fuel Induction WVVT
F652LM-GQMFV
Year 2014 - 2015
Sales region General Frame F652 grade MID body VAN ENGINE 3SZVE DESTINATION GCC From 04.2014 To 08.2015 Gear Shift Type 4AT Driver's Position LHD Fuel Induction WVVT
