Toyota A/C compressor

Auto AC Compressor Assy 88310-0KD60, 883100KD60 INNOVA/ KIJANG/ REVO/ UNSER/ ZACE GUN143 2016-2018
Compressor assembly line, Chongqing
PRODUCTION PLATECompressor assembly line, Chongqing
Toyota A/C compressor

Auto AC Compressor Assy 88310-0KD60, 883100KD60 INNOVA/ KIJANG/ REVO/ UNSER/ ZACE GUN143 2016-2018

OE / Part number
88310-0KD60, 883100KD60

Compresor de aire acondicionado automático de calidad estándar OE OE No.:88310-0KD60, 883100KD60 Product Name:Auto AC Compressor Assy Applications:INNOVA/ KIJANG/ REVO/ UNSER/ ZACE GUN143 2016-2018

What arrives with every unit

  • TRACEProduction record filed against the order line.
  • TESTVacuum, pressure, noise and performance checked before packing.
  • SHIPExport packing with the packing list in the box.
  • SUPPORTApplication engineering available for fitment questions.

§ 01

Inside the compressor

A sectional drawing of a swash-plate compressor, with the six features that decide whether it holds pressure.

1 2 3 4 5 6
1

Control valve

Varies the swash-plate stroke to hold low-side suction pressure steady under changing load.

2

Drive pulley

Poly-V pulley driven from the engine belt; belt tension and alignment decide clutch life.

3

Rotor and swash plate

Pistons run on an inclined swash plate; the inclination sets displacement.

4

Piston and cylinder

Hardened, honed bores sized against the rotor so the swept volume stays on the drawing.

5

Suction port

Low-pressure refrigerant in. Pressure is verified against the test curve before the unit ships.

6

Discharge port

High-pressure gas out to the condenser. Leak tested on every unit.

§ 02

Data sheet

modelTOYOTA A/C Compressor / INNOVA A/C Compressor / REVO A/C Compressor / UNSER A/C Compressor
OE / Part number88310-0KD60, 883100KD60
ApplicationApplications: INNOVA/ KIJANG/ REVO/ UNSER/ ZACE GUN143 2016-2018

§ 03

Product details

OE No.:88310-0KD60, 883100KD60
Product Name:Auto AC Compressor Assy
Applications:INNOVA/ KIJANG/ REVO/ UNSER/ ZACE GUN143 2016-2018

GUN143L-MMMLYM
Year 2016 - 2018
Sales region General Frame GUN143 grade N ENGINE 1GDFTV TRANSMISSION MTM PRODUCT PHLP DESTINATION PHL Model INNOVA From 04.2016 Gear Shift Type 5F Vehicle Model INNOVA Driver's Position LHD
GUN143L-MMMMYM
Year 2016 - 2018
Sales region General Frame GUN143 grade 28G ENGINE 1GDFTV TRANSMISSION MTM PRODUCT PHLP DESTINATION PHL Model INNOVA From 04.2016 Gear Shift Type 5F Vehicle Model INNOVA Driver's Position LHD
GUN143L-MMMSYM
Year 2016 - 2018
Sales region General Frame GUN143 grade 28E ENGINE 1GDFTV TRANSMISSION MTM PRODUCT PHLP DESTINATION PHL Model INNOVA From 04.2016 Gear Shift Type 5F Vehicle Model INNOVA Driver's Position LHD
