Toyota A/C compressor

Auto AC Compressor Assy 88310-0DA10, 883100DA10YARIS/ ECHO/ VIOS/ LIMO NSP150 2013-2018; NSP151 2013-2018
Compressor assembly line, Chongqing
PRODUCTION PLATECompressor assembly line, Chongqing
Toyota A/C compressor

Auto AC Compressor Assy 88310-0DA10, 883100DA10YARIS/ ECHO/ VIOS/ LIMO NSP150 2013-2018; NSP151 2013-2018

OE / Part number
88310-0DA10, 883100DA10

Remanufactured A/C Compressor for car OE No.:88310-0DA10, 883100DA10 Product Name:Auto AC Compressor Assy Applications:YARIS/ ECHO/ VIOS/ LIMO NSP150 2013-2018 NSP151 2013-2018

What arrives with every unit

  • TRACEProduction record filed against the order line.
  • TESTVacuum, pressure, noise and performance checked before packing.
  • SHIPExport packing with the packing list in the box.
  • SUPPORTApplication engineering available for fitment questions.

§ 01

Inside the compressor

A sectional drawing of a swash-plate compressor, with the six features that decide whether it holds pressure.

1 2 3 4 5 6
1

Control valve

Varies the swash-plate stroke to hold low-side suction pressure steady under changing load.

2

Drive pulley

Poly-V pulley driven from the engine belt; belt tension and alignment decide clutch life.

3

Rotor and swash plate

Pistons run on an inclined swash plate; the inclination sets displacement.

4

Piston and cylinder

Hardened, honed bores sized against the rotor so the swept volume stays on the drawing.

5

Suction port

Low-pressure refrigerant in. Pressure is verified against the test curve before the unit ships.

6

Discharge port

High-pressure gas out to the condenser. Leak tested on every unit.

§ 02

Data sheet

modelTOYOTA A/C Compressor / YARIS A/C Compressor / ECHO A/C Compressor / VIOS A/C compressors
OE / Part number88310-0DA10, 883100DA10
ApplicationApplications: YARIS/ ECHO/ VIOS/ LIMO

§ 03

Product details

OE No.:88310-0DA10, 883100DA10
Product Name:Auto AC Compressor Assy
Applications:YARIS/ ECHO/ VIOS/ LIMO

NSP150 2013-2018
NSP151 2013-2018

NSP150L-AHMRKC
Year 2013 - 2018
Sales region General Frame NSP150 ENGINE 6NRFE TRANSMISSION MTM From 12.2013 Gear Shift Type 5F No.of Doors 5D Model Mark R Driver's Position LHD
NSP150L-AEMRKC
Year 2017 - 2018
Sales region General Frame NSP150 ENGINE 6NRFE TRANSMISSION MTM From 03.2017 Gear Shift Type 5F No.of Doors 4D Model Mark R Driver's Position LHDNSP151L-AHMNKC
Year 2013 - 2018
Sales region General Frame NSP151 ENGINE 7NRFE TRANSMISSION MTM From 12.2013 Gear Shift Type 5F No.of Doors 5D Model Mark N Driver's Position LHD
NSP151L-AHMRKC
Year 2014 - 2018
Sales region General Frame NSP151 ENGINE 7NRFE TRANSMISSION MTM From 10.2014 Gear Shift Type 5F No.of Doors 5D Model Mark R Driver's Position LHD
NSP151L-AHXGKC
Year 2016 - 2018
Sales region General Frame NSP151 ENGINE 7NRFE TRANSMISSION CVT From 08.2016 No.of Doors 5D Model Mark G Driver's Position LHD
NSP151L-AHXNKC
Year 2016 - 2018
Sales region General Frame NSP151 ENGINE 7NRFE TRANSMISSION CVT From 08.2016 No.of Doors 5D Model Mark N Driver's Position LHD
NSP151L-AHXRKC
Year 2016 - 2018
Sales region General Frame NSP151 ENGINE 7NRFE TRANSMISSION CVT From 08.2016 No.of Doors 5D Model Mark R Driver's Position LHD
NSP151L-AEMNKC
Year 2017 - 2018
Sales region General Frame NSP151 ENGINE 7NRFE TRANSMISSION MTM From 03.2017 Gear Shift Type 5F No.of Doors 4D Model Mark N Driver's Position LHD
NSP151L-AEMRKC
Year 2017 - 2018
Sales region General Frame NSP151 ENGINE 7NRFE TRANSMISSION MTM From 03.2017 Gear Shift Type 5F No.of Doors 4D Model Mark R Driver's Position LHD
NSP151L-AEXGKC
Year 2017 - 2018
Sales region General Frame NSP151 ENGINE 7NRFE TRANSMISSION CVT From 03.2017 No.of Doors 4D Model Mark G Driver's Position LHD
NSP151L-AEXNKC
Year 2017 - 2018
Sales region General Frame NSP151 ENGINE 7NRFE TRANSMISSION CVT From 03.2017 No.of Doors 4D Model Mark N Driver's Position LHD
NSP151L-AEXRKC
Year 2017 - 2018
Sales region General Frame NSP151 ENGINE 7NRFE TRANSMISSION CVT From 03.2017 No.of Doors 4D Model Mark R Driver's Position LHD
