Toyota A/C compressor

Auto AC Compressor Assy 88310-02A72, 8831002A72 COROLLA ZRE182 2014-2018
Compressor assembly line, Chongqing
PRODUCTION PLATECompressor assembly line, Chongqing
Toyota A/C compressor

Auto AC Compressor Assy 88310-02A72, 8831002A72 COROLLA ZRE182 2014-2018

OE / Part number
88310-02A72, 8831002A72

Reemplazo del compresor de aire acondicionado del vehículo OE No.:88310-02A72, 8831002A72 Product Name:Auto AC Compressor Assy Applications:COROLLA ZRE182 2014-2018"

What arrives with every unit

  • TRACEProduction record filed against the order line.
  • TESTVacuum, pressure, noise and performance checked before packing.
  • SHIPExport packing with the packing list in the box.
  • SUPPORTApplication engineering available for fitment questions.

§ 01

Inside the compressor

A sectional drawing of a swash-plate compressor, with the six features that decide whether it holds pressure.

1 2 3 4 5 6
1

Control valve

Varies the swash-plate stroke to hold low-side suction pressure steady under changing load.

2

Drive pulley

Poly-V pulley driven from the engine belt; belt tension and alignment decide clutch life.

3

Rotor and swash plate

Pistons run on an inclined swash plate; the inclination sets displacement.

4

Piston and cylinder

Hardened, honed bores sized against the rotor so the swept volume stays on the drawing.

5

Suction port

Low-pressure refrigerant in. Pressure is verified against the test curve before the unit ships.

6

Discharge port

High-pressure gas out to the condenser. Leak tested on every unit.

§ 02

Data sheet

modelTOYOTA A/C Compressor / AUTO A/C compressor / COROLLA A/C compressor
OE / Part number88310-02A72, 8831002A72
ApplicationApplications: COROLLA

§ 03

Product details

OE No.:88310-02A72, 8831002A72
Product Name:Auto AC Compressor Assy
Applications:COROLLA
ZRE182 2014-2018


ZRE182L-GEXGKC
Year 2014 - 2018
Sales region General Frame ZRE182 grade GLXI body SED ENGINE 2ZRFE TRANSMISSION CVT DESTINATION CHI Model COROLLA (CHINA) From 06.2014 No.of Doors 4D Vehicle Model Corolla Driver's Position LHD Fuel Induction HTWC
ZRE182L-GEXVKC
Year 2014 - 2018
Sales region General Frame ZRE182 grade PREM body SED ENGINE 2ZRFE TRANSMISSION CVT DESTINATION CHI Model COROLLA (CHINA) From 06.2014 No.of Doors 4D Vehicle Model Corolla Driver's Position LHD Fuel Induction HTWC
