GMC A/C compressor

A/C Compressor manufacturer China of PXV16-8633/6854003 for OPEL Vectra
Compressor assembly line, Chongqing
PRODUCTION PLATECompressor assembly line, Chongqing
GMC A/C compressor

A/C Compressor manufacturer China of PXV16-8633/6854003 for OPEL Vectra

OE / Part number
PXV16-8609

A/C Compressor manufacturer China of PXV16-8633/6854003 for OPEL Vectra — aftermarket A/C compressor OE PXV16-8609 supplied by FIVER AUTOPARTS CO.,LTD. Send an inquiry for price and availability.

What arrives with every unit

  • TRACEProduction record filed against the order line.
  • TESTVacuum, pressure, noise and performance checked before packing.
  • SHIPExport packing with the packing list in the box.
  • SUPPORTApplication engineering available for fitment questions.

§ 01

Inside the compressor

A sectional drawing of a swash-plate compressor, with the six features that decide whether it holds pressure.

1 2 3 4 5 6
1

Control valve

Varies the swash-plate stroke to hold low-side suction pressure steady under changing load.

2

Drive pulley

Poly-V pulley driven from the engine belt; belt tension and alignment decide clutch life.

3

Rotor and swash plate

Pistons run on an inclined swash plate; the inclination sets displacement.

4

Piston and cylinder

Hardened, honed bores sized against the rotor so the swept volume stays on the drawing.

5

Suction port

Low-pressure refrigerant in. Pressure is verified against the test curve before the unit ships.

6

Discharge port

High-pressure gas out to the condenser. Leak tested on every unit.

§ 02

Data sheet

modelA/C Compressor manufacturer China / A/C Compressor supplier / A/C Compressor for OPEL Vectra / OPEL Vectra A/C Compressor
OE / Part numberPXV16-8609
ApplicationApplications: OPEL

§ 03

Product details

Characters of products from fivercompressor.com
Precision machined ports for OE hose fitment.
Internal pistons are PTFE surface treated for longlife durability;
Robotic weldding for precise and consistent quality;
Internal valves are engineered with light weight aluminum alloy for optimize cooling;
OE connectors are available for most applications, no need reposition or splice wiring during installations;
Bearings structured to withstand tension and stress for maximum durability.

Part Name: A/C Compressor

OE/Cross:6854003/93176868/13191996/6854037/PXV16-8633 PXV16-8609

Compressor Type: PXV16

Clutch info: 120mm 5PK 12V

Applications:

OPEL

VECTRA C 2.2 16V 04.2002 - .0 Saloon
VECTRA C GTS 2.2 16V 08.2002 - .0 Hatchback
SIGNUM 2.2 direct 05.2003 - .0 Hatchback
VECTRA C GTS 2.0 16V Turbo 03.2003 - .0 Hatchback
VECTRA C 2.0 16V Turbo 03.2003 - .0 Saloon
VECTRA C Estate 2.0 Turbo 10.2003 - .0 Estate
SIGNUM 2.0 Turbo 05.2003 - .0 Hatchback
VECTRA C Estate 2.2 direct 10.2003 - .0 Estate
VECTRA C GTS 2.2 direct 10.2003 - .0 Hatchback
VECTRA C 2.2 direct 10.2003 - .0 Saloon
