Toyota A/C compressor

A/C Compressor for vehicle 88310-02B20, 8831002B20 AURIS/ COROLLA WWE185 2015-2018
Compressor assembly line, Chongqing
PRODUCTION PLATECompressor assembly line, Chongqing
Toyota A/C compressor

A/C Compressor for vehicle 88310-02B20, 8831002B20 AURIS/ COROLLA WWE185 2015-2018

OE / Part number
88310-02B20, 8831002B20

Brand new Automobile A/C Compressor OE No.:88310-02B20, 8831002B20 Product Name:A/C Compressor for vehicle Applications:AURIS/ COROLLA WWE185 2015-2018

What arrives with every unit

  • TRACEProduction record filed against the order line.
  • TESTVacuum, pressure, noise and performance checked before packing.
  • SHIPExport packing with the packing list in the box.
  • SUPPORTApplication engineering available for fitment questions.

§ 01

Inside the compressor

A sectional drawing of a swash-plate compressor, with the six features that decide whether it holds pressure.

1 2 3 4 5 6
1

Control valve

Varies the swash-plate stroke to hold low-side suction pressure steady under changing load.

2

Drive pulley

Poly-V pulley driven from the engine belt; belt tension and alignment decide clutch life.

3

Rotor and swash plate

Pistons run on an inclined swash plate; the inclination sets displacement.

4

Piston and cylinder

Hardened, honed bores sized against the rotor so the swept volume stays on the drawing.

5

Suction port

Low-pressure refrigerant in. Pressure is verified against the test curve before the unit ships.

6

Discharge port

High-pressure gas out to the condenser. Leak tested on every unit.

§ 02

Data sheet

modelTOYOTA A/C Compressor / AUTO A/C compressor / COROLLA A/C compressor / AURIS A/C Compressor
OE / Part number88310-02B20, 8831002B20
ApplicationApplications: AURIS/ COROLLA WWE185 2015-2018

§ 03

Product details

OE No.:88310-02B20, 8831002B20
Product Name:A/C Compressor for vehicle
Applications:AURIS/ COROLLA WWE185 2015-2018

WWE185L-DHFGXW
Year 2015 - 2018
Sales region Europe Frame WWE185 body HB ENGINE 1WW TRANSMISSION MTM Model AURIS/ AURIS Hybrid From 05.2015 Gear Shift Type 6F No.of Doors 5D Model Mark G Driver's Position LHD Fuel Induction DCRL
WWE185L-DHFNXW
Year 2015 - 2018
Sales region Europe Frame WWE185 body HB ENGINE 1WW TRANSMISSION MTM Model AURIS/ AURIS Hybrid From 05.2015 Gear Shift Type 6F No.of Doors 5D Model Mark N Driver's Position LHD Fuel Induction DCRL
WWE185L-DHFSXW
Year 2015 - 2018
Sales region Europe Frame WWE185 body HB ENGINE 1WW TRANSMISSION MTM Model AURIS/ AURIS Hybrid From 05.2015 Gear Shift Type 6F No.of Doors 5D Model Mark S Driver's Position LHD Fuel Induction DCRL
WWE185L-DWFGXW
Year 2015 - 2018
Sales region Europe Frame WWE185 body WG ENGINE 1WW TRANSMISSION MTM Model AURIS/ AURIS Hybrid From 05.2015 Gear Shift Type 6F No.of Doors 5D Model Mark G Driver's Position LHD Fuel Induction DCRL
WWE185L-DWFNXW
Year 2015 - 2018
Sales region Europe Frame WWE185 body WG ENGINE 1WW TRANSMISSION MTM Model AURIS/ AURIS Hybrid From 05.2015 Gear Shift Type 6F No.of Doors 5D Model Mark N Driver's Position LHD Fuel Induction DCRL
WWE185L-DWFSXW
Year 2015 - 2018
Sales region Europe Frame WWE185 body WG ENGINE 1WW TRANSMISSION MTM Model AURIS/ AURIS Hybrid From 05.2015 Gear Shift Type 6F No.of Doors 5D Model Mark S Driver's Position LHD Fuel Induction DCRL
WWE185R-DHFGXW
Year 2015 - 2018
Sales region Europe Frame WWE185 body HB ENGINE 1WW TRANSMISSION MTM Model AURIS/ AURIS Hybrid From 05.2015 Gear Shift Type 6F No.of Doors 5D Model Mark G Driver's Position RHD Fuel Induction DCRL
WWE185R-DHFNXW
Year 2015 - 2018
Sales region Europe Frame WWE185 body HB ENGINE 1WW TRANSMISSION MTM Model AURIS/ AURIS Hybrid From 05.2015 Gear Shift Type 6F No.of Doors 5D Model Mark N Driver's Position RHD Fuel Induction DCRL
WWE185R-DHFSXW
Year 2015 - 2018
Sales region Europe Frame WWE185 body HB ENGINE 1WW TRANSMISSION MTM Model AURIS/ AURIS Hybrid From 05.2015 Gear Shift Type 6F No.of Doors 5D Model Mark S Driver's Position RHD Fuel Induction DCRL
WWE185R-DWFGXW
Year 2015 - 2018
Sales region Europe Frame WWE185 body WG ENGINE 1WW TRANSMISSION MTM Model AURIS/ AURIS Hybrid From 05.2015 Gear Shift Type 6F No.of Doors 5D Model Mark G Driver's Position RHD Fuel Induction DCRL
WWE185R-DWFNXW
Year 2015 - 2018
Sales region Europe Frame WWE185 body WG ENGINE 1WW TRANSMISSION MTM Model AURIS/ AURIS Hybrid From 05.2015 Gear Shift Type 6F No.of Doors 5D Model Mark N Driver's Position RHD Fuel Induction DCRL
WWE185R-DWFSXW
Year 2015 - 2018
Sales region Europe Frame WWE185 body WG ENGINE 1WW TRANSMISSION MTM Model AURIS/ AURIS Hybrid From 05.2015 Gear Shift Type 6F No.of Doors 5D Model Mark S Driver's Position RHD Fuel Induction DCRL
