Toyota A/C compressor
A/C Compressor for Lexus GX470/Land Cruiser 4.7 V8 32V /Sequoia 4.7 V8 32V / 4 Runner 4.7 V8 32V 88310-6A161/ 88320-35690
§ 01
A sectional drawing of a swash-plate compressor, with the six features that decide whether it holds pressure.
Control valve
Varies the swash-plate stroke to hold low-side suction pressure steady under changing load.
Drive pulley
Poly-V pulley driven from the engine belt; belt tension and alignment decide clutch life.
Rotor and swash plate
Pistons run on an inclined swash plate; the inclination sets displacement.
Piston and cylinder
Hardened, honed bores sized against the rotor so the swept volume stays on the drawing.
Suction port
Low-pressure refrigerant in. Pressure is verified against the test curve before the unit ships.
Discharge port
High-pressure gas out to the condenser. Leak tested on every unit.
§ 02
§ 03

Part Name: A/C Compressor
OE: 88310-6A161/ 88320-35690
Applications: Lexus GX470/Land Cruiser 4.7 V8 32V /Sequoia 4.7 V8 32V / 4 Runner 4.7 V8 32V
Compressor Info:
Item No : WX-10030
Car Name : Lexus GX470/Land Cruiser 4.7 V8 32V/ Sequoia 4.7 V8 32V / 4 Runner 4.7 V8 32V
TYPE : 10S20C
Year model: 2001-2003
OEM No : 88310-6A161/ 88320-35690
Clutch information : 114mm 6PK 12V
Oil type : PAG 46
Oil Quantity : 200ml
