AC Compressor Assy 88310-0R014, 883100R014 for Toyota Camry LE, SE, XLE, XSE 2.5L and RAV4RAV4. 2.5L
OE 88310-0R014, 883100R014
FIVER AUTOPARTS CO.,LTD
Toyota A/C compressor
OE standard Quality Auto A/C Compressor OE No.:88310-WB001, 88310WB001 Product Name:A/C Compressor Applications:SCION IA/YARIS R DD1C 2015-2018 DD1D 2015-2018
§ 01
A sectional drawing of a swash-plate compressor, with the six features that decide whether it holds pressure.
Control valve
Varies the swash-plate stroke to hold low-side suction pressure steady under changing load.
Drive pulley
Poly-V pulley driven from the engine belt; belt tension and alignment decide clutch life.
Rotor and swash plate
Pistons run on an inclined swash plate; the inclination sets displacement.
Piston and cylinder
Hardened, honed bores sized against the rotor so the swept volume stays on the drawing.
Suction port
Low-pressure refrigerant in. Pressure is verified against the test curve before the unit ships.
Discharge port
High-pressure gas out to the condenser. Leak tested on every unit.
§ 02
§ 03


OE No.:88310-WB001, 88310WB001
Product Name:A/C Compressor
Applications:SCION IA/YARIS R DD1C 2015-2018
DD1D 2015-2018
DD1C-NAA
Year 2015 - 2016
Sales region U.S.A. Frame DD1C grade BASE body SED ENGINE P5 TRANSMISSION MTM CATEGORY A Model YARIS R From 08.2015 Engine 1500 To 08.2016 Gear Shift Type 6F No.of Doors 4D Vehicle Model YARIS R Destination MXC
DD1C-NAB
Year 2016 - 2018
Sales region U.S.A. Frame DD1C grade BASE body SED ENGINE P5 TRANSMISSION MTM CATEGORY B Model YARIS R From 08.2016 Engine 1500 Gear Shift Type 6F No.of Doors 4D Vehicle Model YARIS R Destination MXCDD1D-NAA
Year 2015 - 2016
Sales region U.S.A. Frame DD1D grade BASE body SED ENGINE P5 TRANSMISSION ATM CATEGORY A Model YARIS R From 08.2015 Engine 1500 To 08.2016 Gear Shift Type 6FC No.of Doors 4D Vehicle Model YARIS R Destination MXC Vsc LVSC
DD1D-NAB
Year 2015 - 2016
Sales region U.S.A. Frame DD1D grade HI body SED ENGINE P5 TRANSMISSION ATM CATEGORY B Model YARIS R From 08.2015 Engine 1500 To 08.2016 Gear Shift Type 6FC No.of Doors 4D Vehicle Model YARIS R Destination MXC Vsc LVSC
DD1D-NAD
Year 2016 - 2018
Sales region U.S.A. Frame DD1D grade BASE body SED ENGINE P5 TRANSMISSION ATM CATEGORY D Model YARIS R From 08.2016 Engine 1500 Gear Shift Type 6FC No.of Doors 4D Vehicle Model YARIS R Destination MXC Vsc LVSC
DD1D-NAC
Year 2016 - 2018
Sales region U.S.A. Frame DD1D grade HI body SED ENGINE P5 TRANSMISSION ATM CATEGORY C Model YARIS R From 08.2016 Engine 1500 Gear Shift Type 6FC No.of Doors 4D Vehicle Model YARIS R Destination MXC Vsc LVSC
§ 04
OE 88310-0R014, 883100R014
OE 88310-52720, 8831052720, 88310-0D400
OE 88310-52750, 8831052750
OE 88310-02850, 8831002850
