Toyota A/C compressor

A/C Compressor88310-0DA30, 883100DA30 YARIS/ ECHO/ VIOS/ LIMO NSP150 2013-2016
Compressor assembly line, Chongqing
PRODUCTION PLATECompressor assembly line, Chongqing
Toyota A/C compressor

A/C Compressor88310-0DA30, 883100DA30 YARIS/ ECHO/ VIOS/ LIMO NSP150 2013-2016

OE / Part number
88310-0DA30, 883100DA30

Compresor de aire acondicionado automático de calidad estándar OE OE No.:88310-0DA30, 883100DA30 Product Name:A/C Compressor Applications:YARIS/ ECHO/ VIOS/ LIMO NSP150 2013-2016

What arrives with every unit

  • TRACEProduction record filed against the order line.
  • TESTVacuum, pressure, noise and performance checked before packing.
  • SHIPExport packing with the packing list in the box.
  • SUPPORTApplication engineering available for fitment questions.

§ 01

Inside the compressor

A sectional drawing of a swash-plate compressor, with the six features that decide whether it holds pressure.

1 2 3 4 5 6
1

Control valve

Varies the swash-plate stroke to hold low-side suction pressure steady under changing load.

2

Drive pulley

Poly-V pulley driven from the engine belt; belt tension and alignment decide clutch life.

3

Rotor and swash plate

Pistons run on an inclined swash plate; the inclination sets displacement.

4

Piston and cylinder

Hardened, honed bores sized against the rotor so the swept volume stays on the drawing.

5

Suction port

Low-pressure refrigerant in. Pressure is verified against the test curve before the unit ships.

6

Discharge port

High-pressure gas out to the condenser. Leak tested on every unit.

§ 02

Data sheet

modelTOYOTA A/C Compressor / YARIS A/C Compressor / ECHO A/C Compressor / LIMO A/C Compressor
OE / Part number88310-0DA30, 883100DA30
ApplicationApplications: YARIS/ ECHO/ VIOS/ LIMO NSP150 2013-2016

§ 03

Product details

OE No.:88310-0DA30, 883100DA30
Product Name:A/C Compressor
Applications:YARIS/ ECHO/ VIOS/ LIMO NSP150 2013-2016


NSP150L-AHPNKC
Year 2013 - 2016
Sales region General Frame NSP150 ENGINE 6NRFE TRANSMISSION ATM From 12.2013 To 08.2016 Gear Shift Type 4FC No.of Doors 5D Model Mark N Driver's Position LHD
NSP150L-AHPRKC
Year 2013 - 2016
Sales region General Frame NSP150 ENGINE 6NRFE TRANSMISSION ATM From 12.2013 To 08.2016 Gear Shift Type 4FC No.of Doors 5D Model Mark R Driver's Position LHD
