Toyota A/C compressor
A/C Compressor 447600-2270 / 447190-6121 / 447260-0667/447260-5820 for Toyota Passo 1.0i /Subaru Justy 1.3/ Daihatsu Sirion 1.3/Daihatsu Boon 1.0
§ 01
A sectional drawing of a swash-plate compressor, with the six features that decide whether it holds pressure.
Control valve
Varies the swash-plate stroke to hold low-side suction pressure steady under changing load.
Drive pulley
Poly-V pulley driven from the engine belt; belt tension and alignment decide clutch life.
Rotor and swash plate
Pistons run on an inclined swash plate; the inclination sets displacement.
Piston and cylinder
Hardened, honed bores sized against the rotor so the swept volume stays on the drawing.
Suction port
Low-pressure refrigerant in. Pressure is verified against the test curve before the unit ships.
Discharge port
High-pressure gas out to the condenser. Leak tested on every unit.
§ 02
§ 03

Part Name: A/C Compressor
OE: 447600-2270 / 447190-6121 / 447260-0667/447260-5820
Applications: Toyota Passo 1.0i /Subaru Justy 1.3/ Daihatsu Sirion 1.3/Daihatsu Boon 1.0
Compressor Info:
Item NO. : WX-10044
Car Name : Toyota Passo 1.0i /Subaru Justy 1.3
Daihatsu Sirion 1.3/Daihatsu Boon 1.0
TYPE : SV07C
Year model : 2007-
OEM No : 447600-2270 / 447190-6121 / 447260-0667 447260-5820
Clutch information : 108mm 6PK 12V
Oil type : PAG 46
Oil Quantity : 120ml
§ 04
