COMPRESSOR J8832035260 VW TARO
OE J8832035260
FIVER AUTOPARTS CO.,LTD
VW A/C compressor
AC COMPRESSOR ASSY 6R0820803B 6R0820803A 6RF820803 VOLKSWAGEN POLO/DERBY/VENTO-IND — aftermarket A/C compressor OE 6R0820803B supplied by FIVER AUTOPARTS CO.,LTD. Send an inquiry for price and availability.
§ 01
A sectional drawing of a swash-plate compressor, with the six features that decide whether it holds pressure.
Control valve
Varies the swash-plate stroke to hold low-side suction pressure steady under changing load.
Drive pulley
Poly-V pulley driven from the engine belt; belt tension and alignment decide clutch life.
Rotor and swash plate
Pistons run on an inclined swash plate; the inclination sets displacement.
Piston and cylinder
Hardened, honed bores sized against the rotor so the swept volume stays on the drawing.
Suction port
Low-pressure refrigerant in. Pressure is verified against the test curve before the unit ships.
Discharge port
High-pressure gas out to the condenser. Leak tested on every unit.
§ 02
§ 03
§ 04
OE J8832035260
OE 1S0820803B, 1S0820803A
OE 1K0820803F, 1K0820859E, 1K0820803L
OE 7L6820803H, 7L6820803B
