FIVER AUTOPARTS CO.,LTD

VW A/C compressor

AC COMPRESSOR ASSY 5K0820803C 1K0820859T 1K0820859S VOLKSWAGEN BEETLE
Compressor assembly line, Chongqing
PRODUCTION PLATECompressor assembly line, Chongqing
VW A/C compressor

AC COMPRESSOR ASSY 5K0820803C 1K0820859T 1K0820859S VOLKSWAGEN BEETLE

OE / Part number
5K0820803C, 1K0820859T, 1K0820859S, 1K0820808E, 1K0820808C, 5C0820803G, 5C0820803A, 5C0820803B, 1K0820859R, 1K0820808A

AC COMPRESSOR ASSY 5K0820803C 1K0820859T 1K0820859S VOLKSWAGEN BEETLE — aftermarket A/C compressor OE 5K0820803C supplied by FIVER AUTOPARTS CO.,LTD. Send an inquiry for price and availability.

What arrives with every unit

  • TRACEProduction record filed against the order line.
  • TESTVacuum, pressure, noise and performance checked before packing.
  • SHIPExport packing with the packing list in the box.
  • SUPPORTApplication engineering available for fitment questions.

§ 01

Inside the compressor

A sectional drawing of a swash-plate compressor, with the six features that decide whether it holds pressure.

1 2 3 4 5 6
1

Control valve

Varies the swash-plate stroke to hold low-side suction pressure steady under changing load.

2

Drive pulley

Poly-V pulley driven from the engine belt; belt tension and alignment decide clutch life.

3

Rotor and swash plate

Pistons run on an inclined swash plate; the inclination sets displacement.

4

Piston and cylinder

Hardened, honed bores sized against the rotor so the swept volume stays on the drawing.

5

Suction port

Low-pressure refrigerant in. Pressure is verified against the test curve before the unit ships.

6

Discharge port

High-pressure gas out to the condenser. Leak tested on every unit.

§ 02

Data sheet

OE / Part number5K0820803C, 1K0820859T, 1K0820859S, 1K0820808E, 1K0820808C, 5C0820803G, 5C0820803A, 5C0820803B, 1K0820859R, 1K0820808A
ApplicationVOLKSWAGEN BEETLE [BE2012-2013 / BEETLE CONVERTIBLE [BEC] 2013 / JETTA [JEM]2011-2013

§ 03

Product details

Part Name: A/C Compressor assy
Part Number: 5K0820803C 1K0820859T 1K0820859S 1K0820808E 1K0820808C 5C0820803G 5C0820803A 5C0820803B 1K0820859R 1K0820808A
Application: VOLKSWAGEN BEETLE [BE2012-2013 / BEETLE CONVERTIBLE [BEC] 2013 / JETTA [JEM]2011-2013
Remarks: A/C compressor; SANDEN; CBZB,CNWA,; CAVD,CTKA,; CTHD+; PR-9AB,9AK+; 8Z4,8Z5,8Z7

§ 04

Similar compressors

No.CompressorClutchPulley
