VW A/C compressor

AC COMPRESSOR 701820807A 701820805 701820805Q VOLKSWAGEN EUROVAN
Compressor assembly line, Chongqing
PRODUCTION PLATECompressor assembly line, Chongqing
VW A/C compressor

AC COMPRESSOR 701820807A 701820805 701820805Q VOLKSWAGEN EUROVAN

OE / Part number
701820807A, 701820805, 701820805Q

AC COMPRESSOR 701820807A 701820805 701820805Q VOLKSWAGEN EUROVAN — aftermarket A/C compressor OE 701820807A supplied by FIVER AUTOPARTS CO.,LTD. Send an inquiry for price and availability.

What arrives with every unit

  • TRACEProduction record filed against the order line.
  • TESTVacuum, pressure, noise and performance checked before packing.
  • SHIPExport packing with the packing list in the box.
  • SUPPORTApplication engineering available for fitment questions.

§ 01

Inside the compressor

A sectional drawing of a swash-plate compressor, with the six features that decide whether it holds pressure.

1 2 3 4 5 6
1

Control valve

Varies the swash-plate stroke to hold low-side suction pressure steady under changing load.

2

Drive pulley

Poly-V pulley driven from the engine belt; belt tension and alignment decide clutch life.

3

Rotor and swash plate

Pistons run on an inclined swash plate; the inclination sets displacement.

4

Piston and cylinder

Hardened, honed bores sized against the rotor so the swept volume stays on the drawing.

5

Suction port

Low-pressure refrigerant in. Pressure is verified against the test curve before the unit ships.

6

Discharge port

High-pressure gas out to the condenser. Leak tested on every unit.

§ 02

Data sheet

OE / Part number701820807A, 701820805, 701820805Q
ApplicationVOLKSWAGEN EUROVAN [EU]1992- 1996 [70-T-199 999]

§ 03

Product details

Part Name: Compressor, air conditioning
Part Number: 701820807A 701820805 701820805Q
Application: VOLKSWAGEN EUROVAN [EU]1992- 1996 [70-T-199 999]
Remarks: a/c compressor; for refrigerant:; for vehicles with 2nd evapora-; tor the oil capacity must be; increased to 105 cm3; also use:; R134A; 701 820 811 C

§ 04

Similar compressors

No.CompressorClutchPulley
