VW A/C compressor

AC COMPRESSOR 5N0820803H 1K0820808F 1K0820808D VOLKSWAGEN BEETLE
Compressor assembly line, Chongqing
PRODUCTION PLATECompressor assembly line, Chongqing
VW A/C compressor

AC COMPRESSOR 5N0820803H 1K0820808F 1K0820808D VOLKSWAGEN BEETLE

OE / Part number
5N0820803H, 1K0820808F, 1K0820808D, 1K0820808DX

AC COMPRESSOR 5N0820803H 1K0820808F 1K0820808D VOLKSWAGEN BEETLE — aftermarket A/C compressor OE 5N0820803H supplied by FIVER AUTOPARTS CO.,LTD. Send an inquiry for price and availability.

What arrives with every unit

  • TRACEProduction record filed against the order line.
  • TESTVacuum, pressure, noise and performance checked before packing.
  • SHIPExport packing with the packing list in the box.
  • SUPPORTApplication engineering available for fitment questions.

§ 01

Inside the compressor

A sectional drawing of a swash-plate compressor, with the six features that decide whether it holds pressure.

1 2 3 4 5 6
1

Control valve

Varies the swash-plate stroke to hold low-side suction pressure steady under changing load.

2

Drive pulley

Poly-V pulley driven from the engine belt; belt tension and alignment decide clutch life.

3

Rotor and swash plate

Pistons run on an inclined swash plate; the inclination sets displacement.

4

Piston and cylinder

Hardened, honed bores sized against the rotor so the swept volume stays on the drawing.

5

Suction port

Low-pressure refrigerant in. Pressure is verified against the test curve before the unit ships.

6

Discharge port

High-pressure gas out to the condenser. Leak tested on every unit.

§ 02

Data sheet

OE / Part number5N0820803H, 1K0820808F, 1K0820808D, 1K0820808DX
ApplicationVOLKSWAGEN BEETLE [BE]2012-2013 / BEETLE CONVERTIBLE [BEC]2013 / CC [CC]2012-2013 / EOS [EOS]2011-2013 / GOLF/R32/GTI/RABBIT [GO]2012-2013 / JETTA [JEM]2011-2013 / TIGUAN [TIG]2012-2013

§ 03

Product details

Part Name: Compressor, air conditioning
Part Number: 5N0820803H 1K0820808F 1K0820808D 1K0820808DX
Application: VOLKSWAGEN BEETLE [BE]2012-2013 / BEETLE CONVERTIBLE [BEC]2013 / CC [CC]2012-2013 / EOS [EOS]2011-2013 / GOLF/R32/GTI/RABBIT [GO]2012-2013 / JETTA [JEM]2011-2013 / TIGUAN [TIG]2012-2013
Remarks: a/c compressor; SANDEN; PR-8Z5

§ 04

Similar compressors

No.CompressorClutchPulley
